The Wi-Fi compatible HUUM HIVE Mini 9 floor-mounted sauna heater is designed for sauna rooms with dimensions from 317 to 530 cubic feet.

The HIVE Mini 9 provides a traditional sauna experience by creating a consistent, radiant heat each bathing session. The sauna unit features durable stainless-steel construction and comes equipped with industrial-quality heating elements. The Mini 9 sauna heater provides long-lasting beauty, strength, and durability. The unit's large 330-pound stone capacity ensures a soft, consistent, high heat. The heater is designed so that its sauna rocks are in direct contact with its heating elements for more efficient heat transference. The heater includes adjustable legs for added flexibility.

The HUUM HIVE Mini 9 heater operates at 9kW, 240V, single-phase (1PH).

The HIVE Mini 9 sauna unit requires a UKU control or UKU WiFi control for operation. Select the available control with features that best suit your preferences. The available HUUM UKU mobile app lets you preset the sauna from anywhere via smartphone for the ultimate convenience.

HUUM HIVE sauna heaters are precision-crafted for years of dependable operation and worry-free sauna enjoyment. HUUM heaters are designed, engineered, and precision-crafted in Estonia.

The HIVE Mini 9 sauna heating unit carries HUUM's limited 5-year warranty and is fully serviceable. All HUUM Heaters are SGS Listed for your safety.

Hive Mini 9.0kW Sauna Heater
- Elegant design
- 240V/1PH operation
- For sauna rooms from 317 to 530 cu. ft.
- Works with UKU controls (sold separately)
- 330 pound stone capacity (required 10 boxes sold separately)
- Direct contact between stones and heating elements
- More exposed stones create a longer and milder heat
- Stainless steel construction
- Stainless steel, industrial quality heating elements
- Floor model with adjustable legs
- Designed, engineered, and made in Estonia
- Dimensions: 18.1" Diameter (460mm) x 29.5" H (750mm)
- SGS Listed
- Limited 5-year warranty (excluding elements)
UKU
- Sleek Black control display panel
- Multiple Color Options available (additional charges apply)
- Settable on/off, time, temperature, and delay
- Settable temperature range of 104-230F
- Delayed start up to 48hrs in advance
- Optional Built-in Wi-Fi interface for HUUM mobile app (additional charges apply)
- 8 Language options: English, German, Russian, Italian, Finnish, Estonian, Polish and French
- Inside/outside sauna room installation
- Optional smart heating setting
- Available decorative control display panels
- Displays set temperature and room temperature
- Temperature sensor
- Door sensor to keep the heat inside the room
- Remotely located main control module
- Connects to lights and ventilation
- Overheat protection
- Child safety lock
- Control Console Dimensions: 2.2"W (55mm) x 0.9"D (22mm) x 4.1"H (105mm)
- Main Control Module Dimensions: 3.5"W (90mm) x 2.3"D (58mm) x 5.6"H (142mm)
Stones 24
- Olivine diabase sauna stones
- Rounded shape to complement heater design
- Durable with high-heat capacity
- Stones range from 2" to 4" (5-10 cm)
Hive Mini 9
- Kilowatt Rating: 9.0 KW
- Minimum Cubic Feet: 317 CF
- Maximum Cubic Feet: 530 CF
- Heater Weight: 36 lbs
- Shipping Weight with Sauna Stones: 366 lbs
- 240V, Single Phase Amperage: 37.5 Amps
- Circuit Breaker: 50
- Wire Size AWG: 8
- Diameter: 18.1" (460mm)
- Height: 29.5" (750mm)
UKU
- Minimum Temperature Setting: 104 F
- Maximum Temperature Setting: 230 F
- Shipping Weight: 20 lbs
- Console Dimensions
- Width: 2.2" (55mm)
- Depth: 0.9" (22mm)
- Height: 4.1" (105mm)
- Main Module Dimensions
- Width: 3.5" (90mm)
- Depth: 2.3" (58mm)
- Height: 5.6" (142mm)
- Display Panel Cable
- Length: 9.8 ft
- AWG: 22
- Temp Sensor Cable
- Length: 16.4 ft
- AWG: 24
- Door Sensor Cable
- Length: 16.4 ft
- AWG: 24
HIVE Mini 9kW Sauna Heater
- 9.0kW Sauna heater
- Adjustable legs
- Installation and Operation manual
- 5-Year limited warranty (excluding elements)
UKU
- Black Control console
- Main control module
- Temperature sensor
- Door sensor
- Control display panel cable
- Temperature sensor cable
- Door sensor cable
- Installation and operation manual
- 5-Year limited warranty
Stones 24
- 330 lbs of 2" - 4" (5-10 cm) round Olivine sauna stones
- Rail HM (Safety Rail for HIVE Mini heaters). Beautiful light-colored wooden arcs complement the design of the heater.
- The Air Tunnel has been a HIVE option that speeds up heating by 25%, enhances air circulation, and increases the lifespan of the heating elements. This stainless-steel housing is installed in the center of the heater and will reduce stone capacity by an estimated 2 boxes.
- The embedding flange is useful when you are planning to install your HIVE heater partly inside the sauna bench.
